Butyl Extruder Machine

Product Specification

Main Specification and character:

1 it is automatic butyl extruder

2 the whole body frame is made by CNC bended stainless steal

3 applied 5.7 inches color man-machine interface, at the same time, PLC Control system can be oriented and transfer

4 adopt stepless speed regulation and ensure aluminum frame transmission stable

5 Auto-induction system induct aluminum width and adjust the distance between nozzles, which can make extrude evenly.

6 this machine adjust import pneumatic and hydraulic supercharging system and make supply voltage stable, guarantee extrude evenly

7 adopt MAXIMATOR hydraulic pump from Germany, it is so stable and can run 2milion times. It is free of lubrication system

8 Cylinder’s diameter is 195mm. cylinder lining is firstly made by coarse grinding and then hard chromium plating. Finally, after refined grinding to reach needed size.

9 butyl cylinder can contain 14L butyl and it is so convenient and save time.

Technical parameter

Machine sizes 950mm(H)*600mm(w)*3000mm(L)

Spacer width 6-25mm

Minimal size 250mm*250mm

Maximal size 2500mm*2500mm

Speed 0-25m/min

Butyl volume 14L(2blocks)

Power source   3p;380V;50HZ

Total power 3.75kw

Air pressure   8kgf/c

Main spare parts

PLC Omron Japan

Booster pump Maximator Germany

Switching power suply Omron Japan

Low voltage device SIMENS GERMANY

Pneumatic component Airtac Taiwan

Touch screen KINCO Japan

Electromagnetic valve Autos ItalyTemperature controller Omron Japan
